Produktbeskrivelse
Beskrivelse: FU 420 M
Serie: Zebra
Pakkestørrelse: 36
Monokrystalinsk N-Type IBC solcellemodul 420 Watt peak med sort ramme og panel LxBxH: 1895×1039×30mm , Stik: MC4 Kabel 1400mm
MECHANICAL SPECIFICATIONS
Dimensions 1895 x 1039 x 30 mm
Weight 21.0 kg
Glass High transmission, Low iron, Tempered, ARC,
Thickness, 3.2 mm
Cells 132 N-Type half-cut IBC cells 166 x 83 mm
Frame Black anodized aluminium frame with mounting
and drainage holes
Junction boxes Certified according to IEC 62790, IP 68 approved,
3 bypass diodes
Cables Solar cable, length 1400 mm or customized
assembled with MC4-original plugs
Maximum reverse current (Ir) 20 A
Maximum system voltage 1500 V
(1000 V on request)
Mechanical load (snow) Design load: 3600 Pa
5400 Pa (including safety factor 1,5)
Mechanical load (wind) Design load: 1600 Pa 2400 Pa (including safety factor 1,5)
Protection Class II - accordance to IEC 61730
ELECTRICAL DATA - STC* FU 420 M
Module power (Pmax) W 420
Open circuit voltage (Voc) 45.91 V
Short circuit current (Isc) 11.66 A
Maximum power voltage (Vmpp) 38.74 V
Maximum power current (Impp) 10.85 A
Module efficiency % 21.3
